GEN-X Full-Range Class D 4-Channel Amplifier
Secure Checkout
Shop by Categories
Secure Checkout
DS18’s GEN-X Series has a successor and is guaranteed to boost all systems to the top-of-the-line performance! The brand new G1000.4D is designed for the competitor and enthusiast on the journey to creating the system of their dreams!
The G1000.4D delivers pure power with unmatched reliability and efficiency so you can trust the heart of your system will never give out.
As a Class D amplifier, the G1000.4D uses Class D circuitry components significantly smaller than your average amplifier, making it the perfect size for any vehicle’s custom build: but, what it lacks in size it makes up for in power.
The DS18 G1000.4D is a compact full-range Class D 4-channel amplifier delivering up to 1000W MAX, making it a great choice for powering mid-bass drivers, mid-range speakers, vocals, and highs with strong, clean output in a space-saving design.
Protect your equipment effectively with Protection, Clipping, and Power Indicator LED’s that notify you when your amplifier has reached it’s limit!
The G1000.4D has a power output of 300W x 2 CH bridged at 4-ohms, 150W x 4 CH at 2-ohms, 90W x 4 CH at 4-ohms: perfect power settings to supercharge any custom build.
Highlights
Great For





| SPECIFICATIONS | |
| POWER | |
| Total Watts (Peak) | 1000W |
| RMS Power @ 4 ohm | 4 x 90W |
| RMS Power @ 2 ohm | 4 x 150W |
| RMS Power @ 1 ohm | - |
| RMS Power @ 4 ohm Bridge | 2 x 300W |
| AUDIO | |
| Frequency Response | 20Hz-20Khz |
| Signal to Noise Ratio | >90dB |
| Efficiency @ 4ohm | 0.92 |
| Damping Factor | 78 |
| Input Impedance | 22K |
| Channel Separation | 55dB |
| Total Harmonic Distortion (THD) | 0.0001 |
| Low Level Input Range | 0.25-6V |
| High Level Input | Yes |
| Selectable X-Over | LPF/FLAT/HPF |
| X-Over Filter Range | 50Hz-2KHz |
| Bass Boost Range | N/A |
| Bass Boost Frequency | N/A |
| Infrasonic Filter | N/A |
| Phase Selector | No |
| FEATURES | |
| Amplifier Class | Digital (D) |
| Amplifier Type | 4CH Full Range |
| Number of Channels | 4CH |
| Minimum Impedance | 2ohm St / 4ohm Bridge |
| Led Indicator | Power / Protection / Clip |
| Power Input Terminal Size | 4ga |
| Fuse Size | 2 X 25A |
| Remote Level Control | No |
| Cooling Fan | No |
| Voltmeter | No |
| Thermal Protection | Yes |
| Over-Load Protection | Yes |
| DC Output Protection | Yes |
| Short Circuit Output Protection | Yes |
| Voltage Input Protection | Yes |
| Clipping Protection | Yes |
| Body Color / Finish | Matte black |
| MEASUREMENT | |
| Overall Length | 8.1" / 205mm |
| Overall Wide | 4.72" / 120mm |
| Overall Height | 1.96" / 50mm |
| Heatsink Length | 6.2" / 158mm |
| Gross Single Unit Weight | 1.2KG |
