PRO 6.5" Coaxial Hybrid Mid-Range Water resistant Cone Loudspeaker with Built-in Driver 225 Watts Rms 4-Ohm
PRO 6.5" Coaxial Hybrid Mid-Range Water resistant Cone Loudspeaker with Built-in Driver 225 Watts Rms 4-Ohm
PRO 6.5" Coaxial Hybrid Mid-Range Water resistant Cone Loudspeaker with Built-in Driver 225 Watts Rms 4-Ohm
PRO 6.5" Coaxial Hybrid Mid-Range Water resistant Cone Loudspeaker with Built-in Driver 225 Watts Rms 4-Ohm
PRO 6.5" Coaxial Hybrid Mid-Range Water resistant Cone Loudspeaker with Built-in Driver 225 Watts Rms 4-Ohm
Click to zoom in

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    Installation Available

  • Nationwide Delivery

    Fast shipping on in-stock items

PRO 6.5" Coaxial Hybrid Mid-Range Water resistant Cone Loudspeaker with Built-in Driver 225 Watts Rms 4-Ohm

DS18
PRO-HY6.4B
Car Audio : Loudspeakers, Motorcycle : Loudspeakers
$114.95

Secure Checkout

  • Amazon
  • American Express
  • Apple Pay
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa

customers are viewing this product
PRO 6.5" Coaxial Hybrid Mid-Range Water resistant Cone Loudspeaker with Built-in Driver 225 Watts Rms 4-Ohm

DS18 PRO-HY6.4B 6.5" Water Resistant Mid-Range Loudspeaker with Built-in Driver 450 Watts 4-Ohm

DS18's Hybrid speakers give you the best of both worlds of mids and highs combined into one pro audio combination speaker.

This high powered pro audio mega speaker combines both a 6.5 high volume midrange speaker that also has a high wattage driver attached to the rear to give you a full range of frequencies at an amazingly loud volume.

These Hybrids have water resistant cones to help battle elements and are perfect for people looking to place a high wattage, high volume loudspeaker together without having to separately mount am additional driver.

Highlights

  • Hybrid design combines high wattage midrange and driver together in one beautiful frame.
  • High volume 6.5 and 1" driver rated at 225w RMS and 450max for crazy loud volume in a full range of frequencies.
  • Water resistant cone to help battle elements and moisture making them great for motorcycles, boats, and regular vehicles too!

hybrid mid-range loudspeaker with built-in driver

hybrid mid-range loudspeaker with built-in driver

hybrid mid-range loudspeaker with built-in driver

hybrid mid-range loudspeaker with built-in driver

Technical Details
                                           PRO-HY6.4B Product Manual

SPECIFICATIONS
Nominal Diameter 6.5”
Nominal Impedance 4 OHMS
RMS Power Handling 225W
MAX Power Handling 450W
Sensitivity (1w/1m) 96dB
Frequency Response 100Hz-20KHz
Recommended Hi Pass Crossover 120 Hz
Number of Ways 2
Pair or Single Single
MID-RANGE SPECIFICATIONS
Voice Coil Diameter 1.5” / 38.6 mm
Voice Coil Former Material Glass Fiber
Winding Material CCAW
Cone Material Water Resistant Paper
Surround Material Cloth
Basket Material Aluminum
Basket Color/Finish Glossy Red
Magnet Material Ferrite
Magnet Weight 27 oz
Displacement volumen 0.047L
THIELE & SMALL PARAMETERS
Equivalent Volume Vas 2.211L
Excursion (one way) Xmax 9.2 mm
Free Air Resonance FS 199Hz
Mechanical Factor Qms 5.96
Electrical Factor Qes 1.524
Total Factor Qts 1.214
Mechanical Mass Mms 8.654g
Mechanical Compliance Cms 73.792 mm/N
BL Factor BL 4.769
Voice Coil Inductance Le 4.22mH
Cone Area Sd 145.26 Cm2
DC Resistance Re 3.2 ohms
Mechanical Mass w/o Air Mmd 6.7g
DRIVER SPECIFICATIONS
Voice Coil Diameter 1” / 25.4 mm
Voice Coil Former Material Kapton
Winding Material CCAW
Diaphragm Material Titanium
Magnet Material Neodymium
Horn Diameter 3.26"
MEASUREMENTS
Overall Diameter 6.85" / 174 mm
Overall Depth 4.28" / 108.8 mm
Front Mount Baffle Cutout 5.91" / 150 mm
Mounting Depth 3.92" / 99.5 mm
Motor Diameter 4.65" / 118 mm
