Single-DIN Digital Media Receiver Mech-Less Player, Bluetooth, Dual USB ,7 Volt Preouts

DS18
SDX1
Car Audio : Multimedia
$95.95

customers are viewing this product
Single-DIN Digital Media Receiver Mech-Less Player, Bluetooth, Dual USB ,7 Volt Preouts

DS18 SDX1 Single Din Digital Media Receiver Mech-Less Player, Bluetooth, Dual USB ,7 Volt Preouts

Your radio is the driving source of all your music and feeds your amplifiers a clean signal that ensures long life and amazing sound quality out of your sound system. The SDX1 was designed to do just that, along with providing you precise and easy to use controls to get the most out of your audio experience.

This mech-less single din, perfect fit unit pushes out 50 watts max for all 4 channels while the pre-amp output is adjustable up to 7v, which is very important for maximizing the most out of your amplifiers and getting the cleanest sound while maintaining high volume levels. Mech-less means this unit has no CD/DVD player. However, there is a USB, SD, and BT reader that are used for the main file sources that stream and read up to 64GB drives. Radio stations will come in strong and clear and can be set on any of the 18 memory locations.

You can also set the colors of the unit because of the backlit RGB keys to match your mood or existing color schemes, while the easy to read 3 inch VA white display remains bright and clear. You can tune your sound easily with the 2 band equalizer which also allows you to adjust vital functions like level, bass, treble, balance, fade, and subwoofer controls precisely and with ease. Connect to your USB easily with two front USB ports which both have charging functionality with an added front AUX input jack.

The SDX1 is sure to be the best starting decision you can make if you are looking for a single din, high powered head unit, with high pre-amp voltage and tons of additional options to start your audio build.

Highlights

  • Mech-less Single Din USB/BT Receiver
  • Single Din Perfect Fit Mounting
  • FM Radio: 18 Memory Locations
  • Source: USB, SD, BT Reader / Streamer
  • Supported Media Files: MP3, WMA, FLAC, MAV
  • Remote control: Infrared
  • RGB: 7 Selectable Colors
  • Display: 3" VA White Backlit
  • Power: 50 x 4 Watts Max
  • Equalizer: 2 Bands with Adjustable Bass, Treble, and Subwoofer
  • Pre-amp output: 7v
  • Inputs: USB, SD, BT, Front AUX


Good for:

    • Car Audio
    • DIY Projects

Technical Details
                                            SDX1M Product Manual

GENERAL
Rated power source 14.4V DC (11V to 16V operation)
Maximum Current Consumption 10 Amp
Dimensions (W x H x DI: Chassis 178mm x 50mm x 150mm
Bezel frame 188mm x 58mm x 30mm
Weight 15.9 Oz / 452 grams
DISPLAY
Screen Size 3” / 75 x 25mm
Display Type VA LCD
Temperature Operation -20°C to +60°C (14°F to 140°F)
AUDIO
Maximum Power Output 50W X 4 Ch @ 4 ohm (14.4v)
Continuos Power Output 17W x 4 Ch @ 4 ohm (14.4v)
Pre-output Level 7 Volts (14.4V)
Equalizer 2 bands (Bass: 60Hz, Treble: 10KHz)
Gain +/- 7dB
Preset EQ Jazz / Rock / Pop / Classic
Audio Control Volume / Balance / Fader / Loudness / Bass / Treble
Subwoofer Control Vol (0-20) / Cut (80/120/160 Hz)
Signal to Noise Ratio >60dB
THD <0.3%
Frequency Response 20Hz – 20Khz
TUNER
Frequency Range FM: 87.5 ~ 107.9 KHz
Presets Memory 18 Stations
Region North America “USA”
Sensitivity Adjustment LOC / DX & ST / Mono
Sensitivity <20dB
Stereo Separation >25dB
USB / SD PLAYER
Type/Class V1.1 / V2.0 / MSC / MTP / FAT16 / FAT32 / NTFS
Format Files Supported MP3, WMA, FLAC, MAV
Info Display Format ID3 Tag
Memory Size Reader up to 64 Gb
Max Current Supply 1.5 Amp (Charging USB port)
Number of USB Ports 2 x Front (1 for Audio / 1 for Charging)
SD Slot 1 x Front Micro SD
CONNECTIVITTY
Bluetooth Version / Services V4.1 / Audio Streaming / Hands Free calls
Audio Protoco A2DP v1.2 Sink (SNK)
Aux input Front 3.5mm Jack Stereo Audio
Microphone Built-In Microphone on faceplate
Remote Control Frontal IR Receptor
